Sectional Sno-Pusher

Sectional Sno-Pusher™ by Arctic: The Only Plow You’ll Ever Need

Why You Need the Sectional Sno-Pusher Today…

  • Easy to Use – Drop ‘N Go
  • Scrapes Down to Pavement
  • Reduces Costly Repairs
  • Eliminate Follow Up Plowing
  • Safest Plow to Use
  • Universal Mounting System

The Sectional Sno-Pusher’s unique design equips the user for simple and efficient plowing on any uneven surface. The moldboards are no more than 32” wide and narrow enough to scrape snow out of dips in the pavement. Moving up and down independently and contouring to uneven surfaces, the plow will clear virtually all snow from the pavement in just one pass. No need for any follow-up plowing, which is common with a wide one piece moldboard snow pusher. The Sectional Sno-Pusher eliminates the expense to own and operate, or sub-contract a plow truck, and will pay for itself within the first winter of average use.

Trips Over Obstacles…

The sectional pusher patented design includes a spring-loaded trip cutting edge, and four polyurethane mounting blocks that enable each moldboard section to easily trip over obstacles up to 9 inches high.

  • 32-inch-wide individual moldboards sections are mounted to the mainframe with engineered polyurethane mounting blocks.
  • Each moldboard section has three torsion springs attached to the steel cutting edge.
  • The spring trip steel cutting edge is forced backward upon impact and easily clears smaller obstacles.
  • Once the steel cutting edge is forced backward 45°, the moldboard moves up, bending the polyurethane mounting blocks to clear larger obstacles up to 9 inches high.

Reduces Costly Repairs

If you damage a steel cutting edge, you only need to replace one edge, instead of several feet of costly steel or rubber cutting edge. Simply remove the damaged edge and replace it. In the unlikely event that the operator causes major damage to any component of the plow, it can be removed and replaced with a new OEM replacement part. With conventional snow pushers, major damage usually results in a total loss.

Snow pushers with fixed side panels are difficult for an operator to adjust the wear – shoes to lay flat on the pavement. This constant incorrect alignment results in premature shoe wear.

The Sectional Sno-Pusher’s shoes always automatically lay flat on the surface. Made of AR-400 hardened steel, the shoe will last several winters of commercial use.

Raise Over Obstacles

The mechanical side panels move upward and downward upon impact to clear obstacles hidden beneath the snow.

  1. The side panel moves upward to clear obstacles such as curbs
  2. The side panel rides on top of the curb, while the rest of the plow remains flat
  3. The panel returns to down position after clearing the obstacle

Eliminate Follow Up Plowing

Unlike the Sectional Sno-Pusher, a snow pusher’s rubber cutting edge can leave packed snow uncleared from the pavement, and a follow-up plowing with a pickup is needed to clear unplowed snow from the pavement before salting.

Safest Plow To Use

Because of the Sectional Pusher’s patented design, it is the most forgiving plow on the market. The Sectional Sno-Plow was designed to be forgiving and less rigid upon impact. Other snow pushers on the market are essentially fixed mounted dozer blades that can result in major damage to equipment or severe injury to the operator.

Universal Mounting Options

  1. Change mounting hook-up type in minutes, one plow fits all.
  2. Direct bucket hook-up mount.
  3. Remove 2” pins and existing mounting hook-up.
  4. Install Factory OEM quick coupler mounting hook-up of your choice and reinstall 2” pins.

Easy To Use – Drop ‘N Go

  • Slip-Hitch travels on 2 inch pins
  • When other snow pushers are lowered, the front tires are lifted off the ground, reducing traction

The unique patented Slip-Hitch™ enables an operator to lower the Sectional Sno-Pusher and go! The Slip-Hitch automatically adjusts the Sectional Sno-Pusher to the pavement grade and enables the Sectional Sno-Pusher to float up and down freely from the machine while continuously adjusting to the pavement.

The Slip-Hitch assures that all four tires remain on the pavement, providing the machine full traction and reducing drag. Conventional snow pushers are fix-mounted very much like dozer blades and can elevate the machine’s front tires with improper down pressure, reducing traction and creating drag. With no added drag, the Sectional Sno-Plow can quickly push snow across large parking lots. The mechanical side panels rest flat on the surface automatically every time. Just drop the Sectional Sno-Plow on the pavement and go!

Scrapes Down To Pavement


The Sectional Sno-Pusher uses 32” wide independent moldboards instead of the traditional 1-piece moldboard, allowing the Sectional Sno-Pusher freedom to move up and down depending on the surface. This technology enables the plow to contour to the grade of any surface. Because of this patented design, the AR400 hardened steel trip-cutting edge scrapes packed snow and ice down to the pave­ment far superior to a rubber cutting edge.

Turn your idle equipment into a fast effective snow removal fleet and enjoy big profits all winter!

Choose the Sectional Sno-Plow that fits your needs!

Model Width in Feet Weight in Pounds Capacity in Yards (Approx.) Min. HP.
SKID STEER LD-8 8.02 1,400 10 50
LD-10 10.5 1,700 13 70
LD-12 13 2,000 16 80
LD-14 15.5 2,200 19 85
BACKHOE LD-10 10.5 1,700 13 70
LD-12 13 2,000 16 80
LD-14 15.5 2,200 19 85
HD-12 11.25 3,300 19 85 W/4WD
COMPACT LOADER LD-10 10.5 1,700 13 50
LD-12 13 2,000 16 60
LD-14 15.5 2,200 19 70
LOADER HD-12 11.25 3,300 19 1.5 YD
HD-14 13.81 3,700 23 2 YD
HD-16 16.54 4,100 28 2.5 YD
HD-19 19.27 4,500 35 3 YD
HD-22 21.98 4,900 39 4-5 YD

LD = light duty (32” high x 57” deep) for smaller machines up to 18,000 lbs.
HD = heavy duty (46” high x 72” deep) for larger machines up to 18,000 lbs. or greater
